Thursday, September 27, 2007

VdB142 "Elephant Trunk" in Ha:sG:OIII

click here
©2007 Richard Murray

Full Size Image

Techno Stuff: 6/20/07 Camera: ATK-16hr, Imaging Scope: Megrez 80mm APO at F/6, mounted on LX90 8" SCT, Ha 6nm 80 min total with 20 min subs, OIII 14nm 90 min total with 30 min subs, no binning, Darks Applied, Autoguided with QGuide and PHDGuide from LX90, , Processed with CCDStack, Photoshop CS2, PixInsight

Notes: This is an Ha:sG:OIII narrowband image with Ha mapped as red, OIII as blue and a synthetic green generated from the Ha and OIII images. I took this back on June 20th but didn't have a chance to process it until now.

I didn't plan on the colors turning out this way but I think the black and orange are appropriate with Halloween just around the corner. :>))

In the two images below the colors are remapped to red:green:blue respectively.

Here's an Ha:OIII:OIII version.

click here
©2007 Richard Murray

Full Size Image

And here's an OIII:Ha:OIII version.

click here
©2007 Richard Murray

Full Size Image

And here is a collage of all three.
