Saturday, November 14, 2009

NGC2070 Tarantula Nebula Southern Hemisphere


©2009 Richard Murray


Notes: The Tarantula is a giant emission nebula within our neighboring galaxy the Large Magellanic Cloud. It is so bright that if it were the same distance as the Orion Nebula it would cast shadows!

The image above is a stack of five 10 minute H-Alpha filtered exposures.

I also took red, green and blue exposures which I will process later.

Date(s): 11/12/09
Object(s): NGC 2070 Tarantula Nebula
Telescope: RCOS 16" - FL 3360mm @ f/8.4
Mount: Paramount ME
Camera: SBIG STL-1001E - NABG
Guiding: On Camera
Filters: Ha
Exposure(s): 5 x 600 sec Ha, Binning 2x2
Processing: CCDStack and Photoshop
Location: Moorook, South Australia

Thursday, October 29, 2009

M104 Sombero Galxaxy How It Was Done

I can't give you all of the particulars of how I processed this image because my methods vary with each one but I certainly can give you an overview so here it goes:

CCD Stack -

The luminance images were loaded into CCDStack and calibrated with darks, flats and bias applied. Then an std sigma reject was applied to all images and the rejected pixels were imputed. Then a positive constraint deconvolution was applied with 100 iterations. The images were then registered, normalized and stacked using a sum combine. A DDP adjustment was then applied on the summed image with auto scale and adjustments were made to background, maximum and gamma settings. The image was then saved as a 16 bit .tif file. All of the same functions were applied to the red and blue frames with the exception of deconvolution and the fact that a maximum combine instead of a sum was used for stacking.

Photoshop CS2 -

On the luminance image, I used space noise reduction from Noel Carboni's Astronomy Tools and star trail elimination from Peter's Actions for Astrophotographers.

I applied a median filter to process out some black artifacts that resulted from a poor dark subtraction.

I switched to lab color and deselected all but the lightness channel and saved the image (this brings about an overall brightening of the image).

I applied a coarse high pass sharpening to the galaxy core and rim.

There was some grainyness to the image background so I did a gaussian blur subtraction using Apply Image with blending set to subtract and an offset of 25.

LRsGB processing was done by following a combination of Steve Cannistra's 'Modified Bicolor Technique' and R. Scott Ireland's LRGB procedures from his book 'Photoshop Astronomy'. A synthetic green channel was created prior to color processing. A couple of action steps applied to the color image were soft color gradient removal and increase star color.

There were many other steps applied in Photoshop in the .tif and .jpg formats too numerous to mention (or remember for that matter).

Registax 3 -

Wavelet filters were applied here. That's all.

PixInsight 1.0-

A dynamic background extraction was applied and prior to image sharpening an SGBNR smoothing routine was applied.
________

Here is the absolutely final widefield full resolution image (honest) of M104. There were two minor corrections done in Photoshop. First, three large stars in the image were damaged because they weren't protected during processing, so I replaced them with the stars as they were before processing. Second, the top star halo of M104 was too blotchy and unnatural so I lassoed the area and went to the filter menu and selected Pixelate and applied the fragment function to the area which took care of most of the blotchies.

Be sure to click on the image for the full widefield view:

click here
©2008 Richard Murray
Full Size Image

Monday, August 31, 2009

Next Imaging Target CED214 Emission Nebula


©2008 Richard Murray


Notes: This large emmision nebula in the constellation Cepheus (also known as the Calf Nebula) will be my next narrowband imaging target. I'll start the project as soon as the moon goes away around mid September. This one will be a minimum of 18 hours imaging with 6 hours for each narrowband filter (Ha, OIII, SII).

I think this one holds a lot of promise with a large amount of nebulosity and structure.

The image above is a single shot 240 second Ha exposure.

Date(s): 8-30-09
Object(s): Emission Nebula in Cepheus
Telescope: Megrez 66mm SD Doublet APO, WO 0.8 FR/FF
Mount: LX90
Camera: Atik 16hr
Guiding: Lx90 8" SCT, DSI Pro, Phd Guiding
Filters: Ha
Exposure: 240 sec Ha, Binning 2x2
Processing: CCDStack and Photoshop
Location: Burke Ave. Observatory, Three Rivers, Michigan

Friday, August 21, 2009

Two New Images With Widefield Scope


©2008 Richard Murray


Notes: Here's a couple of unprocessed test images I took last night with my new 66mm Doublet APO. I was having trouble achieving focus until I put a 20mm extender in the optical chain which finally did the job.

What I like about these images is the wider field of view, but most important the stars are nice and round right to the edges of the image. So there's no dreaded vignetting going on. Also because of the short focal length (about F4.7 with the 0.8focal reducer) the ccd exposure times can be shorter. The left image was taken with an Ha filter for 4 minutes and the right image with a red filter for 3 minutes.

More images soon . . . .

Date(s): 8-20-09
Object(s): IC1396 Elephant Trunk Nebula in Cepheus and M31 the Andromeda Galaxy in Andromeda
Telescope: Megrez 66mm SD Doublet APO, WO 0.8 FR/FF
Mount: LX90
Camera: Atik 16hr
Guiding: Lx90 8" SCT, DSI Pro, Phd Guiding
Filters: Ha 6nm, Red
Exposure: 240 sec Ha, 180 sec Red, Binning 2x2
Processing: CCDStack - Quick DDP
Location: Burke Ave. Observatory, Three Rivers, Michigan

Thursday, May 28, 2009

Springtime At Burke Avenue Observatory


©2008 Richard Murray

For the past six months, I've been taking a hiatus from imaging. I'll eventually get back into astronomy but I'm trying to decide if I should continue with imaging and image processing or maybe focus on a more 'scientific' area of amatuer astronomy. A couple of areas I've been considering are supernova or comet hunting and possilby exoplanet hunting. All of these endeavors are possible even with the modest equipment I have available.

A great article on amatuer supernova hunting 'Searching for Supernovae on a Shoestring' appeared in the July 2009 issue of Sky & Telescope. I have the same ccd imager that the author uses.

So I'll continue to ponder for awhile what part of the universe I want to explore. Until then keep looking up.

Rick Murray

Sunday, November 16, 2008

IC1848 Soul Nebula Stero Pair

Below are stereo pairs of my recent Soul Nebula image.

The first image is the parallel version. Just stare at the middle of the two images and another image should appear in 3D.

The second image is the cross version. Just stare at the center of the image while crossing your eyes and another image should appear in 3D.

Parallel Vision Image Pair


©2008 Richard Murray

Cross Vision Image Pair


©2008 Richard Murray

These were created using J-P Metsavainio's Stero Pair Action for Photoshop which can be found here: Stero Pair Action

Monday, October 20, 2008

NGC1491 Emission Nebula in Perseus

click here
©2008 Richard Murray
Full Size Image


Notes: This is an emission nebula in the constellation Perseus. The nebulas glow is caused by hot gas plasma that is excited by embedded energetic young stars including the central star, BD+50 886 (mag 11.2) which is responsible for the brightest area with it's own blister nebula and glowing columns of gas.

The color palette used for this image was: OIII Red, SII Green, Ha Blue. This gives the image some unusual colors but helps to show how dynamic and active this region really is.

Imaging with narrowband is sometimes like looking at an object from an aliens perspecive whose eyes don't perceive colors the way we do but whose vision may in some ways be superior to our own.

Date(s): 10-8, and 10-12-08
Object: NGC 1491 Emission Nebula in Perseus
Telescope: Megrez 80mm APO, WO 0.8 FR/FF
Mount: LX90
Camera: Atik 16hr
Guiding: Lx90 8" SCT, DSI Pro, Phd Guiding
Filters: Ha 6nm, OIII 15nm, SII 14nm
Exposure: 9 hrs total, Ha 10x30 mins, OIII 6x20 mins, SII 6x20 mins, Binning 1x1
Processing: CCDStack, Photoshop CS2, PixInsight
Location: Burke Ave. Observatory, Three Rivers, Michigan

Read More

Tuesday, October 07, 2008

IC1848 Soul Nebula

An Angel in the Soul


©2008 Richard Murray

Full Soul

click here
©2008 Richard Murray
Full Size Image


Minimal Stars Soul

click here
©2008 Richard Murray
Full Size Image



Notes: This is my second narrowband project which is the Soul Nebula right next door to the Heart Nebula. The weather wasn't as cooperative this time but I did manage to get most of the image exposures I needed. I got a full six hours of Ha but only managed half that for the OIII and SII filters. Still, it turned out pretty well.

Be sure to click on the image for a full size view and also at the bottom, the Read More link will take you to a great article in Universe today about this colorful nebula.

Date(s): 10-3, and 10-4-08
Object: IC1848 Soul Nebula in Cassiopeia
Telescope: Megrez 80mm APO, WO 0.8 FR/FF
Mount: LX90
Camera: Atik 16hr
Guiding: Lx90 8" SCT, DSI Pro, Phd Guiding
Filters: Ha 6nm, OIII 15nm, SII 14nm
Exposure: 11 hrs 20 mins Ha 12x30 mins, OIII 10x20 mins, SII 6x20 mins, Binning 1x1
Processing: CCDStack, Photoshop CS2, PixInsight, Hubble Palette: SII=Red,Ha=Green,OIII=Blue
Location: Burke Ave. Observatory, Three Rivers, Michigan

Read More

Sunday, September 28, 2008

IC1805 Heart Nebula in Narrowband

Second version with less stars.

click here
©2008 Richard Murray
Click on image for 80% size.

Zoomed in to image center.


©2008 Richard Murray


click here
©2008 Richard Murray
Full Size Image


Notes: This was an imaging run that took three nights to complete with 6 hours per filter and 30 minute subs for a total of 18 hours imaging. I've never imaged that long on one object before but I think the effort was worth it. I used the Hubble Palatte with SII as Red, Ha as Green and OIII as blue.

Be sure to click on the image for a full size view.

Date(s): 9-21, 9-22 and 9-25-08
Object: IC1805 Heart Nebula in Cassiopeia
Telescope: Megrez 80mm APO, WO 0.8 FR/FF
Mount: LX90
Camera: Atik 16hr
Guiding: Lx90 8" SCT, DSI Pro, Phd Guiding
Filters: Ha, OIII, SII
Exposure: 18 Hours Ha 12x30 mins, OIII 12x30 mins, SII 12x30 mins, All Bin 1x1
Processing: CCDStack, Photoshop CS2
Location: Burke Ave. Observatory, Three Rivers, Michigan

Read More

Thursday, September 04, 2008

CTB-1 Supernova Remnant in Narrowband

click here
©2008 Richard Murray
Full Size Image


Notes: This is a supernova remnant sometimes referred to as Abell 85 located near the star Caph in the constellation Cassiopeia.

This reminds me of Simeis 147 I made an attempt at imaging a while back which is also an extremely faint remnant: here

I decided to image this using narrowband (Ha mapped to red, OIII to green, and SII to blue) filters to try to get as much detail as possible during the short amount of time I had.

CTB-1 is rarely imaged by amatuer astronomers and currently I could find only two examples on the internet. The second link refers to Dean Rowe's image which he took just recently in HaRGB and was my inspiration to give this challenging object a try:

Image of Bottom Half of CTB-1

Dean Rowe's Image

To me this object looks like a cell wall which has just burst open with its contents flowing out towards the upper left.

Coordinates: RA 23:59:13 DEC +62:26:12

Be sure to click on the image for a full size view.

Date: 8/31/08
Object: CTB-1 Supernova Remnant
Telescope: Megrez 80mm APO, WO 0.8 FR/FF
Mount: LX90
Camera: Atik 16hr
Guiding: Lx90 8" SCT, DSI Pro, Phd Guiding
Filters: Ha, OIII, SII
Exposure: 200 Minutes Ha 1x10,2x20,3x30 min subs, OIII 1x20 min sub, SII 2x20 min subs
Processing: CCDStack, Photoshop CS2
Location: Burke Ave. Observatory, Three Rivers, Michigan
